Product Size
Product Parameters
| Model | A | B | C | D | E | Tooth pitch |
| L-04 | 49.5 | 23 | 23 | 10 | 14 | 1.5*60° |
| L-05 | 62 | 25 | 30 | 10 | 14 | 1.5*60° |
| L-06 | 73 | 31 | 36 | 12 | 20 | 1.5*60° |
| L-08 | 95 | 35 | 37 | 14 | 25 | 1.5*60° |
| L-10 | 110 | 40 | 42 | 16 | 30 | 1.5*60° |
| L-12 through-hole | 130 | 50 | 50 | 21 | 30 | 1.5*60° |
| L-12 solid | 130 | 50 | 50 | 18 | 30 | 1.5*60° |
| L-15 through-hole | 165 | 62 | 62 | 22 | 43 | 1.5*60° |
| L-15 solid | 165 | 62 | 62 | 25.5 | 43 | 1.5*60° |
| L-21/24 inch | 180 | 65 | 70 | 25 | 60 | 3.0*60° |
| *The above dimensions are standard dimensions, if there are non-standard dimensions, they can be customized. | ||||||
-
